Full Automatic Industrial Dryer Machine, Clothes Dryer, Tumble Dryer
1. Fast drying performance
2. Micro processor control. temperature control and over-temperature protection device installed.
3. Durable stainless steel drum , prevent the fabric from pollution, anti-corrosion.
4. Concentrated airflow and sealed drum ensure maximum air utilization and energy savings to improve drying efficiency.
5. Heat-exchanger adopt seamless pipe to make higher thermal efficiency.
6. Advanced structure, fewer moving parts mean fewer maintenance problems and less wear.
7. Heating: electrical, steam, electrical and steam, gas/LPG.
8. Easy accessibility to the vital parts, easy service, quick replacement of the belt.
9. Large door, easy loading and unloading, opens 180°, option: left or right opening.
Specification:
|
Model |
Unit |
HG(Q)-15 |
HG(Q)-25 |
HG(Q)-35 |
HG(Q)-50 |
HG(Q)-70 |
HG(Q)-100 |
HG(Q)-150 |
|
Max Drying Capacity |
kg |
15 |
25 |
35 |
50 |
70 |
100 |
150 |
|
Drum Dimension (DxL) |
mm |
Φ760x650 |
Φ960x650 |
Φ960x1000 |
Φ1200x870 |
Φ1280x890 |
Φ1500x1100 |
Φ1600x1480 |
|
Motor Power |
kw |
0.55 |
0.75 |
0.75 |
1.1 |
1.1 |
2.2 |
3 |
|
Fan power |
kw |
0.55 |
0.75 |
0.75 |
1.1 |
1.1 |
2.2 |
3 |
|
Rated Voltage |
V |
110/220/240/380/415/440v |
|
|||||
|
Drying time |
mins |
≤40 |
≤40 |
≤40 |
≤40 |
≤40 |
≤40 |
≤40 |
|
Exhaust diameter |
mm |
140 |
200 |
200 |
250 |
280 |
280 |
280 |
|
Noisy |
dB(A) |
≤80 |
≤80 |
≤80 |
≤80 |
≤80 |
≤80 |
≤80 |
|
Vibration |
mm/s |
≤7 |
≤7 |
≤7 |
≤7 |
≤7 |
≤7 |
≤7 |
|
Electric Heating power |
kw |
10.8 |
15.5 |
24 |
26.8 |
33 |
39 |
45 |
|
Dimension(L.W.H) |
mm |
840x1100x1620 |
1060x1100x1960 |
1060x1200x1960 |
1310x1500x2200 |
1420x1350x2300 |
1650x1850x2430 |
2230x2100x2430 |
|
N.W. |
kg |
320 |
400 |
450 |
550 |
600 |
1000 |
1550 |
