Fully Automatic Washing Machine
XGQ-F SOFT MOUNTED WASHER EXTRACTOR
Laundrymachine.cn
XGQ-100F[Q]
It Adopts The Latest International Cylinder Block Full Suspension Structure To Avoid Vibration.
The Fully Enclosed Rear Drainage Frame Structure Does Not Pollute The Environment.
The Inner Tank And Outer Shell Are Made Of High-Quality Stainless Steel, Which Is Resistant To Corrosion And Durable.
It Adopts The Latest International Cylinder Block Full Suspension Structure To Avoid Vibration.
The Washing Tank System Is Suspended And Installed On The Spring And Shock Absorption Device, And The Shock Absorption Is More Than 95%, And No Foundation Is Required For Use.
Equipped With An Automatic Detergent Dispersing Container, Neither The Accumulation Of Soap Powder Nor The Inadequate Dissolution Of Additives Will Cause The Linen To Burn.
Full Computer Control, Frequency Converter Speed Regulation, Man-Machine Dialogue For Washing Procedures, Fault And Functional Self-Checking System, Greatly Reducing Maintenance Costs.
The High, Medium And Low Water Levels Can Be Adjusted Arbitrarily According To The Actual Situation, And The Washing Operation Can Be Set To A Variety Of Manual Or Automatic Program Control.
Dehydration Safety Control Function, When The Unbalanced Force Is Too Large, It Will Automatically Stop And Alarm, And The Water Temperature Can Be Automatically Controlled At
Product Advantages
The Whole Series Adopts 304 Stainless Steel Drainage System
The Actual Capacity Is Greater Than 100KG, Compared With The Traditional Equipment, The Dehydration Rate Is Higher, And The Loading Capacity Is Larger;
Technical Parameter
|
Model |
Unit |
XGQ-100F【Q】 |
|
Rated Capacity |
Kg |
100 |
|
Inner Cage Size |
Mm |
Φ1230×830 |
|
Motor Power |
Kw |
7.5 |
|
Washing Speed |
Rpm |
32 |
|
Dehydration Speed |
Rpm |
670 |
|
Inverter Power |
Kw |
11 |
|
Electric Heating Power |
Kw |
48 |
|
Steam Pipe |
Mm |
Φ25 |
|
Cold And Hot Water Pipes |
Mm |
Φ50 |
|
Compressed Air Pipe |
Mm |
Φ8 |
|
Compressed Air Pressure |
Mpa |
0.5-0.6 |
|
Water Consumption |
Kg |
1180 |
|
Air Consumption |
Kg |
70 |
|
Inlet Steam Pressure |
Mpa |
0.4-0.6 |
|
Water Inlet Pressure |
Mpa |
0.2-0.3 |
|
Dimensions |
Mm |
1780×2150×2060 |
|
Total Weight |
Kg |
3200 |
High-End Manufacturing
1. American TWB (Timken) Bearings
2. Domestic Well-Known Brand Bangpu Inverter
3. Water Seal Imported From Switzerland, More Durable Than V-Ring
4. Lubrication System Adopts Automatic Oil Pump
5. Fuzhou Characteristic Professional Washing Inverter Motor
6. Bangpu Computer Control Machine, With More Than 30 Automatic Programs
7. On The Basis Of The Full Suspension Structure, The Air High-Tech South Spring Is Used For Double Shock Absorption
